Pylontech Battery, lithium-ion, H2-Force, 7.1 - 14.21kWh

Pylontech H2-Force Battery System 7.1-14.2kWh

The Pylontech H2-Force is a high-voltage modular lithium iron phosphate battery system designed for residential energy storage. Features a slim, furniture-style design with IP55 rating for flexible indoor/outdoor installation.

Key Features

• Scalable from 7.1kWh to 14.2kWh
• 96V high-voltage architecture
• LiFePO4 chemistry for safety and longevity
• 5,000+ cycle life at 90% DoD
• IP55 weather protection
• Slim profile design (450mm wide)
• Cable-free module stacking

Specifications

• Module Capacity: 3.55kWh each
• System Voltage: 96-192V
• Module Capacity: 37Ah at 96V
• Minimum Configuration: 2 modules (7.1kWh)
• Maximum Configuration: 4 modules (14.2kWh)
• Cycle Life: >5,000 at 90% DoD
• Dimensions: 450 x 296 x 822-1414mm
• Round-trip Efficiency: >90%

Applications

• Residential solar self-consumption
• Home backup power
• Time-of-use optimization
• Grid support services

Warranty

10 years standard warranty.
